IPsec Tunnel: PfSense And MikroTik Configuration Guide

by Jhon Lennon 55 views

Creating a secure and reliable network is crucial, and one effective way to achieve this is by setting up an IPsec tunnel between a pfSense firewall and a MikroTik router. An IPsec tunnel provides a secure channel for transmitting data between two networks over the internet, ensuring confidentiality and integrity. This guide will walk you through the process step-by-step, making it easy for even those with limited experience to establish a robust connection. Whether you're a network admin, a tech enthusiast, or just someone looking to secure your home network, this guide will provide all the necessary information.

Understanding IPsec and Tunneling

Before we dive into the configuration, let's briefly discuss what IPsec is and why it's important. IPsec (Internet Protocol Security) is a suite of protocols that secures internet protocol (IP) communications by authenticating and encrypting each IP packet of a communication session. IPsec includes protocols for establishing mutual authentication between agents at the beginning of the session and negotiating cryptographic keys to use during the session. This ensures that the data transmitted remains confidential and cannot be tampered with.

Tunneling, in the context of networking, is the process of encapsulating one network protocol within another. In the case of IPsec, the original IP packets are encapsulated within IPsec packets, which are then transmitted over the internet. At the receiving end, the IPsec packets are decrypted, and the original IP packets are extracted and forwarded to their destination. This creates a secure tunnel through which data can flow safely.

The benefits of using an IPsec tunnel are numerous. Firstly, it provides strong encryption, protecting sensitive data from eavesdropping. Secondly, it ensures data integrity, guaranteeing that the data received is the same as the data sent. Thirdly, it offers authentication, verifying the identity of the communicating parties. Finally, it provides secure site-to-site connectivity, allowing you to connect two geographically separated networks as if they were on the same local network. For businesses, this means secure communication between branch offices, while for individuals, it means secure access to home networks while traveling.

Prerequisites

Before starting, ensure you have the following prerequisites in place:

  • pfSense Firewall: A properly installed and configured pfSense firewall with internet connectivity.
  • MikroTik Router: A MikroTik router with internet connectivity.
  • Static Public IP Addresses: Both the pfSense firewall and the MikroTik router should have static public IP addresses. If you don't have static IPs, you can use Dynamic DNS (DDNS) services, but this guide assumes static IPs for simplicity.
  • Network Configuration: A clear understanding of your network subnets on both sides of the tunnel. For example, the pfSense network might be 192.168.1.0/24, and the MikroTik network might be 192.168.2.0/24. Make sure that the subnets do not overlap.
  • Administrative Access: Administrative access to both the pfSense firewall and the MikroTik router.

Having these prerequisites in place will streamline the configuration process and help prevent common issues. Ensure that both devices are updated to the latest firmware versions to take advantage of the latest security patches and features.

Step-by-Step Configuration: pfSense

Step 1: Configure IPsec Phase 1

Phase 1 of the IPsec configuration establishes the secure channel between the pfSense firewall and the MikroTik router. To configure Phase 1 on pfSense, follow these steps:

  1. Log in to the pfSense web interface.
  2. Navigate to VPN > IPsec.
  3. Click Add P1 to create a new Phase 1 entry.
  4. Key Exchange version: Choose IKEv2.
  5. Internet Protocol: Select IPv4.
  6. Interface: Choose the WAN interface (the interface connected to the internet).
  7. Remote Gateway: Enter the public IP address of the MikroTik router.
  8. Description: Add a description for the tunnel (e.g., "MikroTik IPsec Tunnel").
  9. Authentication Method: Select Mutual PSK.
  10. Pre-Shared Key: Enter a strong, randomly generated pre-shared key. Make sure to note this key, as you will need to enter the same key on the MikroTik router.
  11. Encryption Algorithm: Choose the encryption algorithms you want to use. A good choice is AES256-GCM.
  12. Hash Algorithm: Select a hash algorithm. A good choice is SHA256.
  13. DH Key Group: Choose a Diffie-Hellman key group. A good choice is 14 (2048 bit MODP Group).
  14. Lifetime: Set the lifetime for Phase 1. The default value of 28800 seconds (8 hours) is usually sufficient.
  15. Click Save.

Step 2: Configure IPsec Phase 2

Phase 2 defines the security associations for the actual data transfer. To configure Phase 2 on pfSense, follow these steps:

  1. On the IPsec page, click Add P2 to create a new Phase 2 entry.
  2. Mode: Choose Tunnel IPv4.
  3. Description: Add a description for Phase 2 (e.g., "MikroTik IPsec Tunnel Phase 2").
  4. Protocol: Select ESP.
  5. Encryption Algorithms: Choose the encryption algorithms you want to use. Make sure these match the algorithms chosen in Phase 1. A good choice is AES256-GCM.
  6. Hash Algorithms: Select a hash algorithm. Make sure this matches the algorithm chosen in Phase 1. A good choice is SHA256.
  7. PFS Key Group: Choose a Perfect Forward Secrecy (PFS) key group. A good choice is 14 (2048 bit MODP Group).
  8. Lifetime: Set the lifetime for Phase 2. The default value of 3600 seconds (1 hour) is usually sufficient.
  9. Source Network: Specify the local network behind the pfSense firewall that will be accessible through the tunnel. For example, 192.168.1.0/24.
  10. Destination Network: Specify the remote network behind the MikroTik router that will be accessible through the tunnel. For example, 192.168.2.0/24.
  11. Click Save.
  12. Click Apply Changes to activate the IPsec configuration.

Step 3: Configure Firewall Rules

To allow traffic to pass through the IPsec tunnel, you need to create firewall rules on the pfSense firewall.

  1. Navigate to Firewall > Rules.
  2. Select the IPsec tab.
  3. Click Add to create a new rule.
  4. Action: Choose Pass.
  5. Interface: Select IPsec.
  6. Address Family: Choose IPv4.
  7. Protocol: Select Any.
  8. Source: Choose Any or specify the local network that will be using the tunnel.
  9. Destination: Choose Any or specify the remote network that will be using the tunnel.
  10. Add a description for the rule (e.g., "Allow IPsec Traffic").
  11. Click Save.
  12. Click Apply Changes to activate the firewall rule.

Step-by-Step Configuration: MikroTik

Step 1: Configure IPsec Phase 1

To configure Phase 1 on the MikroTik router, follow these steps:

  1. Log in to the MikroTik router using WinBox or the web interface.
  2. Navigate to IP > IPsec > Peers.
  3. Click the + button to add a new peer.
  4. Address: Enter the public IP address of the pfSense firewall.
  5. Profile: Choose default or create a new profile (see Step 2 for profile configuration).
  6. Exchange Mode: Select ike2.
  7. Send Initial Contact: Check this box to initiate the connection from the MikroTik side.
  8. Secret: Enter the same pre-shared key that you entered on the pfSense firewall.
  9. Click Apply and OK.

Step 2: Configure IPsec Profile

The IPsec profile defines the encryption and hash algorithms used for Phase 1. If you chose to use the default profile in Step 1, you can skip this step. Otherwise, follow these steps to create a new profile:

  1. Navigate to IP > IPsec > Profiles.
  2. Click the + button to add a new profile.
  3. Name: Enter a name for the profile (e.g., "pfSense-Profile").
  4. Hash Algorithm: Choose sha256.
  5. Encryption Algorithm: Choose aes-256.
  6. DH Group: Select modp2048.
  7. Natt Traversal: Select yes.
  8. Click Apply and OK.

Step 3: Configure IPsec Phase 2 (Proposal)

Phase 2, also known as the proposal, defines the security associations for the actual data transfer. To configure Phase 2 on the MikroTik router, follow these steps:

  1. Navigate to IP > IPsec > Proposals.
  2. Click the + button to add a new proposal.
  3. Name: Enter a name for the proposal (e.g., "pfSense-Proposal").
  4. Authentication Algorithms: Choose sha256.
  5. Encryption Algorithms: Choose aes-256-gcm.
  6. Lifetime: Set the lifetime for Phase 2. The default value of 3600 seconds (1 hour) is usually sufficient.
  7. PFS Group: Select modp2048.
  8. Click Apply and OK.

Step 4: Configure IPsec Policy

The IPsec policy defines the traffic that will be protected by the IPsec tunnel. To configure the IPsec policy on the MikroTik router, follow these steps:

  1. Navigate to IP > IPsec > Policies.
  2. Click the + button to add a new policy.
  3. Src. Address: Enter the local network behind the MikroTik router that will be accessible through the tunnel. For example, 192.168.2.0/24.
  4. Dst. Address: Enter the remote network behind the pfSense firewall that will be accessible through the tunnel. For example, 192.168.1.0/24.
  5. Action: Choose encrypt.
  6. IPsec Protocol: Select esp.
  7. Level: Choose require.
  8. Proposal: Select the proposal you created in Step 3 (e.g., "pfSense-Proposal").
  9. Peer: Select the peer you created in Step 1 (the pfSense firewall).
  10. Click Apply and OK.

Verification and Troubleshooting

After completing the configuration on both the pfSense firewall and the MikroTik router, it's important to verify that the IPsec tunnel is working correctly. Here are some steps you can take to verify and troubleshoot the tunnel:

  • Check IPsec Status:
    • pfSense: Navigate to Status > IPsec in the pfSense web interface. You should see the tunnel listed with a status of Established.
    • MikroTik: Navigate to IP > IPsec > Active Peers and IP > IPsec > Active Policies in WinBox or the web interface. You should see the tunnel and policies listed as active.
  • Ping Test:
    • From a device on the pfSense network, ping a device on the MikroTik network. For example, if a device on the pfSense network has the IP address 192.168.1.10 and a device on the MikroTik network has the IP address 192.168.2.10, try pinging 192.168.2.10 from 192.168.1.10. If the ping is successful, the tunnel is working correctly.
  • Firewall Rules:
    • Double-check that the firewall rules on both the pfSense firewall and the MikroTik router are configured correctly to allow traffic to pass through the tunnel.
  • Pre-Shared Key:
    • Ensure that the pre-shared key is the same on both the pfSense firewall and the MikroTik router.
  • Encryption and Hash Algorithms:
    • Verify that the encryption and hash algorithms are the same on both the pfSense firewall and the MikroTik router.
  • Subnet Overlap:
    • Make sure that the subnets on both sides of the tunnel do not overlap. If they do, the tunnel will not work correctly.
  • Logs:
    • Check the logs on both the pfSense firewall and the MikroTik router for any error messages related to the IPsec tunnel. The logs can provide valuable information for troubleshooting.

By following these steps, you can verify that the IPsec tunnel is working correctly and troubleshoot any issues that may arise. If you encounter persistent problems, consult the documentation for both pfSense and MikroTik, or seek assistance from online forums and communities.

Conclusion

Setting up an IPsec tunnel between a pfSense firewall and a MikroTik router can seem daunting, but by following this step-by-step guide, you can create a secure and reliable connection between two networks. IPsec tunnels provide a robust solution for protecting sensitive data and ensuring secure communication. Whether you're a network administrator securing a business network or an individual securing a home network, the benefits of using an IPsec tunnel are undeniable.

From understanding the basics of IPsec and tunneling to configuring the necessary settings on both the pfSense firewall and the MikroTik router, this guide has covered all the essential aspects of setting up an IPsec tunnel. By verifying the tunnel's functionality and troubleshooting any issues, you can ensure that your network is secure and your data is protected.

So go ahead and implement this setup, and enjoy the peace of mind that comes with knowing your network communications are secure. With a little patience and attention to detail, you can create a robust and reliable IPsec tunnel that will serve your network security needs for years to come. Guys, keep exploring new ways to enhance your network security and stay ahead of potential threats!
